LED SEG light box with illuminated frameless graphic

How to Specify an SEG Light Box for a Retail Rollout

A store-by-store SEG light box rollout spec: size matrix, controlled drawing, lighting target, electrical matrix and a three-store pilot plan.

A retail rollout turns one light box into a purchasing system. Ten stores mean ten openings, ten electrical supplies and ten sets of artwork, and the specification has to survive every one of them. The goal is not the best single box but the same result in every store: a graphic that fits, a glow that matches, and a replacement routine a store manager can run without calling an engineer. This guide sets out the documents and decisions that make that repeatable, and the cases where a full rollout specification is more process than the job needs.

What a Rollout Specification Actually Is

A rollout specification is a written package that fixes the product, the drawing, the light and the artwork system before the first store is measured. It has four parts: a store size matrix, one controlled frame drawing, a lighting and electrical standard, and a graphic template with version control. Suppliers quote from this package, factories build from it, and stores receive cartons labelled against it. When the package is missing, each store becomes a separate project, and separate projects drift.

The package does not need to be long. It needs to be the only version in circulation. One drawing number, one revision letter and one artwork template beat a folder of email attachments, because the factory, the installer and the store team all work from the same page.

Why Buyers Care: Three Costs That Escalate With Every Store

Reprints. A visible area that differs by 40 mm from the template means every graphic in the chain is reprinted, and the mistake is found at installation, not at order. A controlled template with the silicone edge and safe area marked prevents it.

Store downtime. If changing a graphic needs a technician, the window stays empty until the technician arrives. SEG graphics are designed to be changed from the front by store staff, and the specification should say so in writing, with the tools and the time per face.

Freight. Frame depth drives carton size, and carton size drives billable weight. A 30 mm profile that suits a mall recess ships in a smaller carton than an 80 mm profile. Standardising the depth across stores is a freight decision as much as a design decision.

How the Specification Is Built: The Store Matrix Comes First

Start with a row per store. Measure the opening, the visible area after any reveal or frame, the available depth, the number of faces and the local power supply. The matrix below shows the structure and the fields; the values are project inputs, not catalogue sizes.

Store typeOpening W x HVisible areaFrame depthFacesMountingSupply
Mall window6000 x 2400 mm5940 x 2340 mm80 mm1Recessed220-240 V
High street2400 x 1600 mm2340 x 1540 mm50 mm2Wall bracket220-240 V
Airport corridor3600 x 1800 mm3540 x 1740 mm50 mm1Suspended220-240 V
Department store4800 x 2000 mm4740 x 1940 mm80 mm2Wall bracket220-240 V
Pop-up unit1200 x 1800 mm1140 x 1740 mm30 mm1Freestanding100-240 V

Two fields are usually missed. The first is the service access: a 6 m face that cannot reach the lift or turn a stair corner becomes a site problem. The second is the ceiling or bulkhead behind the mounting point, which decides whether a bracket can be fixed at all. Add both to the matrix and the installation survey becomes a checklist instead of a surprise.

Where the Same Box Changes by Market

Electrical standards are the obvious difference, and they are the easiest to specify. The US runs 120 V at 60 Hz and usually asks for UL or ETL listed drivers. The UK and Europe run 230 V at 50 Hz, with CE and RoHS documentation and WEEE registration for the destination country. Australia runs 240 V with RCM marking. Gulf projects often run 220-240 V in higher ambient temperatures, so driver derating belongs in the brief.

The less obvious differences are building rules. Mall management may require fire-rated fabric, a specific cable route or an isolation switch within reach. A listed building may forbid new fixings in the facade. A store with a shallow reveal may need a 30 mm profile regardless of the visual target. Record these constraints per store, because they change the frame, not just the paperwork.

Climate matters for outdoor and semi-outdoor faces. A covered mall entrance and an open-air street frontage need different sealing and IP ratings, and the specification should state which face is which. For outdoor units, ask for the IP rating of the complete assembly, not only the power supply.

SEG Fabric vs Acrylic in a Rollout

Both formats can carry a printed brand face. The rollout decision turns on change frequency, face size and freight.

ConsiderationSEG fabric frameAcrylic light box
Graphic changeMinutes, front access, store staffPanel reprint or replacement
Face sizeSpans large openings without jointsLimited by sheet size and weight
FreightFrames flat, graphics rolledHeavy panels, corner protection needed
Surface finishEven fabric glow, soft textureGlossy, glass-like depth
Damage risk in transitLow, fabric is flexibleHigher, edges and faces chip
Best fitCampaign windows that changeFixed premium features

A common pattern mixes both: acrylic for a compact premium feature at the entrance, SEG fabric for the large campaign wall. Keep the colour temperature and brightness target identical, or the two displays will look like they came from different projects.

SEG vs LED Snap Frame: A Third Option Buyers Confuse

A snap frame holds a printed poster behind a hinged aluminium edge. It is cheap, quick to change and well suited to A-series paper sizes. It is not an edge-to-edge fabric system: the frame covers part of the face, the graphic is not tensioned, and large sizes sag or wrinkle. For a rollout with branded window graphics at 2 m and above, SEG is the format that keeps the face clean.

When a Rollout Specification Is the Wrong Tool

Process has a cost, and a two-store project does not need a 40-page manual. The table below is the honest short version.

SituationWhy the full package is overkillWhat to do instead
One or two storesEach store can be measured and quoted directlyOne drawing, one sample, one approved proof
Image fixed for yearsNo artwork churn to controlChoose the finish first, then the frame
Listed or heritage buildingFixings and approvals decide the designSurvey with the landlord before specifying any product
No store staff for changesSEG front access is wastedPlan a service contract or a simpler format

How to Choose: The Seven Documents to Approve

1. Store size matrix. One row per store, with opening, visible area, depth, faces and supply.

2. Controlled frame drawing. One drawing number with a revision letter, showing the profile, corner detail, fixing points and cable entry.

3. Lighting target. Colour temperature, colour rendering, brightness and uniformity, written as measurable values rather than words like bright or warm.

4. Graphic template. The silicone edge allowance, the safe area and the visible area marked on one file that every designer uses.

5. Electrical matrix. Voltage, frequency, plug or terminal type and driver location per market.

6. Carton and label schedule. Store code, drawing revision and face number on every carton, so a pallet can be split without opening boxes.

7. QC and pilot plan. Three to five pilot stores, photographed and measured against the target, before the remaining stores are released.

Common Mistakes in Multi-Store Programs

  • Approving a drawing, not a sample. A drawing cannot show the glow, the fabric hand or the edge finish. Approve a physical sample from the production line.
  • Letting each store keep its own artwork file. Version drift is guaranteed. One template, one register.
  • Quoting frames and graphics separately. The cheapest frame often carries a longer print lead time, and the opening date pays for the difference.
  • Ignoring the reveal. A deep frame in a shallow window looks forced and blocks service access.
  • Skipping the store label. A carton without a store code reaches the wrong city, and the re-ship costs more than the label.
  • Releasing all stores at once. Pilot first. The first three installations always teach something the drawing did not.

Common Questions About This Topic

How many stores should be in a pilot before a full rollout?

Three to five stores covering the main formats is enough to catch fitting, lighting and installation problems. Include one difficult site, such as a shallow reveal or a high ceiling, because that is where the drawing fails.

Should every store use the same frame depth?

Use the same depth wherever the building allows it, and record the exceptions in the matrix. One standard depth simplifies spare parts, cartons and staff training, while a second depth for recessed sites is a manageable exception.

Who owns the artwork template?

The brand or its agency owns the design; the supplier should issue the production template with the silicone edge and safe area marked. Keep the template under version control and send it with every new campaign brief.

How do we keep brightness consistent between stores?

Write a measurable target: colour temperature, colour rendering index, brightness at the face and uniformity across the face. Then measure the pilot stores with the same meter and the same warm-up time.

What spare parts should a rollout carry?

One driver per ten frames, a set of corner connectors, spare silicone-edge graphic for the largest face and a small stock of mounting screws. Match the spares to the frame revision, not to a generic parts list.

Can the same frame be used outdoors?

Only when the assembly is specified for it. Outdoor faces need a sealed enclosure, a suitable IP rating, drainage and a driver rated for the ambient temperature. A standard indoor frame moved outside will fail at the seals.

The Bottom Line on Rollout Specifications

A rollout is won or lost in the documents, not on the production line. Build the store matrix first, approve one drawing and one physical sample, fix the lighting target in numbers, and pilot three stores before releasing the rest. Buyers who do that get identical results in every city; buyers who skip it get a different project in every store.
